VVDI Prog

Original Xhorse VVDI Prog programmer =（BMW ISN READ）+（EERPOM read)+(mcu read MOTO 9S12,5M48,,,,)+PIN CODER Calculation (more pin coder Algorithm ,than 40 type).

Software version: 4.5.2 (keep updating)
Firmware version: V1.2.2

VVDI-prog functions & descriptions

VVDI Prog Main Features:

35080, 080D0, 160D0, erase quickly,erase Can be done in 10 s.
While reading MC9S12 series Chips, VVDI Pro is more stable than XP Prog.
While attacking MC9S12 series Chips, VVDIProg is faster.
While reading some EEPROM Chips, Orange are not able to recognize Chips.
Spared voltage attack function can be used when needed.
Spared CAN Cable, K-Line Cables Can be used when needed.

Once you buy VVDI Prog programmer, you can get free BMW ISN read function and NEC, MPC, Infineon etc chip continuously update service.

VVDIProg read BMW ISN:

VVDI-PROG PCB Layout:

VVDI Prog Supported chip list

EEPROM

Manufactures	Types	Support	Remark
ATMEL	AT24CXX	R
	AT25XXX	R
	AT93CX6	R
BOSCH	B3XX	R
	B4XX	R
	B5XX	R
	B58XXX	R
CATALYST	CAT24CXX	R
	CAT24WXX	R
	CAT93CX6[A]	R
EXEL	XL[S]24CXX	R
	XL[S]93CX6	R
FAIRCHILD	FM24CXX	R
	NM24CXX	R
	NM93CX6	R
GRUNDIG	GRXX	R
HOLTEK	HT93CX6	R
MICROCHIP	24AAXX	R
	24[L]CXX	R
	93[L]CX6	R
	93AAX6	R
MITSUBISHI	M6M800X1	R
SEIKO	S-24CXX	R
SEIKO	S-93CX6	R
ST	D80/D160	R	Can erase the first 32 bytes
ST	M35080	R	Can erase the first 32 bytes
NEC	M24CXX	R
ST	ST24CXX	R
	ST24EXX	R
	ST24WXX	R
	ST25CXX	R
	ST25EXX	R
	ST95P0X	R

Note: R means the type is supported, £ means the type will be supported soon in the future

MCU

Manufactures	Types	Support	Remark
MOTOROLA	MC9S12XEP	R	Can automatically determine D-FLASH/EEE space
	MC9S12XA	R
	MC9S12XB	R
	MC9S12XD	R
	MC9S12XDT	R
	MC9S12XDP	R
	MC9S12XDQ	R
	MC9S12DG	R
	MC9S12DT	R
	MC9S12P	R
	MC9S12H	R
	MC9S12HY	£
	MC9S12HA	£
	MC9S12HZ	£
	MC9S12XHZ	£
	MC9S12B	£
	MC9S12GC	£
	MC9S12XS	£
	MC9S12K	£
	MC9S12Q	£
	MC9S12C	£
	MC9S12P	£
	MC9HC(9)08	£
ATMEL	ATTINY	£
ATMEL	ATMEGEA	£
NEC	uPD70F	£
ST	TMS370	£

Note: R means the type is supported, £ means the type will be supported soon in the future.

ECU

Manufactures	Types	Support	Remark
VAG	MED17.1-TC1796	£
	MED17.11-TC1796	£
	VAG MEG17.5-TC1766	£
	VAG MED17.5.1-TC1796	£
	VAG MED17.5.2-TC1767	£
	VAG MED17.5.5-TC1766	£
	VAG MED17.5.20-TC1766	£
	VAG EDC17 CP14/CP20-TC1796	£
	VAG EDC17 CP04-TC1796	£
	VAG EDC17 C46-TC1767	£
	VAG EDC17 CP24-TC1796	£
	VAG EDC17 CP44-TC1797	£
	VAG EDC17 U01-TC1766	£
	VAG EDC17 U05-TC1796	£
	VAG/Porsche Siemens Continental SDI 3-TC1796	£
BMW	MEVD172(N55)	R
	MEVD172P(N20)	R
	MEVD172G(N55)	R
	MEVD172S(N55)	R
	MEVD1724(N20)	R
	MEVD1725(N13)	R
	MEVD1726(N55)	R
	MEVD1729(N20)	R
	MEVD1728(N63/S63)	R

Note: R means the type is supported, £ means the type will be supported soon in the future.

How to install VVDI Prog software?

How to update VVDI Prog programmer software and firmware?

Software Upgrade:

Open VVDI Pro software

Click “Upgrade” tab

Then come to VVDIProg Update menu. You are able to check software version (Tip Information) and firmware version (Device Information).

Firmware Upgrade:

step 1 – connect the vvdi prog device with the usb cable for the computer

step 2 – click on “Start Firmware Upgrade” button to begin update

step 3 – wait for upgrade to complete

VVDI PROG Software Update Plan:

VVDI Prog V4.5.2 Update Notice:

Original Xhorse VVDI Prog ECU MCU EEPROM programmer released new software version in 2016-11-25.

VVDI PROG V4.5.2 update feature:

v4.5.2 (2016-11-25)
* This version DON’t need update firmware
* Fix some bugs
+ Add VVDI PROG USER MUNUAL 4.5.1 version in Doc folder
+ Add AB28F200B5T(PSOP44),AB28F200B5B(PSOP44),AB28F400B5 T(PSOP44),AB28F400B5B(PSOP44),
AB28F800B5T(PSOP44),AB28F800B5B(PSOP44)options in <1-EEPROM&FLASH>-><INTEL>(Need the TB28FXXX adapter)
+ Add HC908GR4,HC908GR8,HC908LJ12,HC908LJ24, HC908GR4_SECURED, HC908GR8_SECURED, HC908LJ12_SECURED,
HC908LJ24_SECURED options in <2-MCU>-><MOTOROLA-MC69HC(9)08>
+ Add MC9S08JM8_UNSECURED,MC9S08JM16_UNSECURED, MC9S08JM32_UNSECURED, MC9S08JM60_UNSECURED options in <2-MCU>-><MOTOROLA-MC9S08>
+ Add [V850ES/FE3]series: 70F3623 option
[V850ES/FF3]series: 70F3626 option
[V850ES/FG3]series: 70F3627,D70F3629,D70F3630 options
[V850ES/FJ3]series: 70F3631,D70F3632,D70F3633, D70F3634, D70F3635 options
[V850ES/FK3]series: D70F3636,D70F3637,D70F3638 optionsin <2-MCU>-><RENESAS-V850>
+ Add BCM3 option in <4-IMMOBILIZER>-><GM>
+ Add XIAOKANG(2015) option in <5-DASHBORAD>-><DONGFENG>
+ Add SAICMAXUS-RV(2015) option in <5-DASHBORAD>-><SAICMOTOR>
+ Add <7-ARIBAG> option in TYPE
+ Add GL8-SRS(2015) option in <7-ARIBAG>-><BUICK>
+ Add MAKKA-SRS(2015) option in <7-ARIBAG>-><OPEL>
+ Add VW52-SRS-V2 option in <7-ARIBAG>-><VOLKSWAGEN>

Free download VVDI-Prog V4.5.2 software

https://mega.nz/#!DwwmlLYI!cmNf2bJDnskEEqAFs9iJD3NTpEYwfhc368paCOPbo1w

password:123456

VVDIProg V4.5.1 Update Feature:

v4.5.1 (2016-10-24)
* This version DON’t need update firmware
* Fix some bugs
+ Add VVDI PROG USER MUNUAL 4.5.1 version in Doc folder
* Fix MC68HC908 series write FLASH problem
+ Add MB91F037,MB91F061,MB91F062 optionsin <2-MCU>->
+ Add [V850E2/DK4]series: 70F3529 option
[V850E2/FG4]series: 70F3548, D70F3549, D70F3550, D70F4000,D70F4001,D70F4002 options
[V850E2/FJ4]series: 70F3551,D70F3552,D70F3553,D70F3554, D70F4003,D70F4004, D70F4005,D70F4006 options
[V850E2/FK4]series: 70F3555,D70F3556, D70F3557,D70F3558, D70F3592, D70F4007,D70F4008,D70F4009,D70F4010 options
[V850E2/FL4]series: 70F3559,D70F3560,D70F4011,D70F4012 options
[V850E2/FK4-H]series: 70F3561 options
[V850E2/FL4-H]series: 70F3564 options
[V850E2/FE4-L]series: 70F3570, D70F3571,D70F3572 options
[V850E2/FF4-L]series: 70F3573,D70F3574, D70F3575 options
[V850E2/FG4-L]series: 70F3576,D70F3577,D70F3578,D70F3579,D70F3580 options
[V850E2/FJ4-L]series: 70F3582,D70F3583,D70F3584,D70F3585 options in <2-MCU>->
+ Add DISCOVER3-CEM,RANGE-ROVER-SPORT-CEM options in <4-IMMOBILIZER>->
+ Add BIG7-ICU(HC908GZ32) option in <4-IMMOBILIZER>->
+ Add SRS(2016) option in <7-OTHER>->

VVDI Prog V4.5.0 Software Free Download

Password:123456

VVDI-Prog V4.5.0 Update Feature:

v4.5.0 (2016-09-26)
* This version DON’t need update firmware
* Fix some bugs
+ Add VVDI PROG USER MUNUAL 4.5.0 version in Doc folder
* Fix ATMEGAxx8 diagram error problem
* Change D70f3624 diagram(add QFP64 package)
+ Add ATMEGA48P,ATMEGA48PB, ATMEGA88P,ATMEGA88PB, ATMEGA163,ATMEGA164,
ATMEGA164P, ATMEGA168P,ATMEGA168PB, ATMEGA169P,ATMEGA323,ATMEGA324, ATMEGA324P,
ATMEGA324PB, ATMEGA325, ATMEGA325P, ATMEGA3250, ATMEGA3250P, ATMEGA328, ATMEGA328P,
ATMEGA328PB, ATMEGA329, ATMEGA329P,ATMEGA3290, ATMEGA3290P,ATMEGA644, ATMEGA644P,
ATMEGA645, ATMEGA645P, ATMEGA6450, ATMEGA6450P, ATMEGA649, ATMEGA649P, ATMEGA6490,
ATMEGA6490P, ATMEGA103, ATMEGA1284, ATMEGA1284P optionsin <2-MCU>-><ATMEL-ATMEGA_XXXX>
+ Add HC908GZ8,HC908GZ16, HC908GZ32,HC908GZ48,HC908GZ60,HC908GZ8_SECURED,HC9 08GZ16_SECURED,
HC908GZ32_SECURED,HC908GZ48_SECURED,HC908GZ60_SECU RED options in <2-MCU>-><MOTOROLA-MC68HC(9)08>
+ Add MC912DT128_UNSECURED,MC912DT128A_UNSECURED,MC912DT 128P_UNSECURED,MC912DT128_SECURED,
MC912DT128A_SECURED,MC912DT128P_SECURED optionsin <2-MCU>-><MOTOROLA-MC68HC(9)12>
+ Add MT20U2-MC912DT128P option in <3-ECU>-><DELPHI>
+ Add BESTURN-B90-BCM option in <4-IMMOBILIZER>-><FAW>
+ Add FENGGUANG(2016) option in <5-DASHBORAD>-><DONGFENG>
+ Add XC60-HIGH-EQUIPPED(2014) option in <5-DASHBORAD>-><VOLVO>

VVDI-Prog V4.4.9 software free download

Password:123456

VVDI Prog V4.4.9 Update Feature:
* This version DON’t need update firmware
* Fix some bugs
+ Add VVDI PROG USER MUNUAL 4.4.9 version in Doc folder
+ Add ATMEGA48,ATMEGA8,ATMEGA88,ATMEGA16,ATMEGA162,
ATMEGA168,ATMEGA169,ATMEGA32,ATMEGA64,ATMEGA640,AT MEGA128,
ATMEGA1280,ATMEGA1281,ATMEGA2560,ATMEGA2561 optionsin <2-MCU>-><ATMEL-ATMEGA_XXXX>
+ Add XC164CS-16F,XC164CS-32F options in <2-MCU>-><INFINEON-XC164CS>
+ Add PIC18F6520,PIC18F6620,PIC18F6720,PIC18F8520,PIC18F 8620,
PIC18F8720 options in <2-MCU>-><MICROCHIP-PIC18F>
+ Add MODUS-XC164CS-32F option in <3-ECU>-><RENAULT>
+ Add X7(2016) option in <5-DASHBORAD>-><HANTENG>
+ Add HONDA(2015) option in <5-DASHBORAD>-><HONGDA>
+ Add ESL-HC08GR16-V1 option in <7-OTHER>-><AUDI>
+ Add ATCM,RFA-V2 options in <7-OTHER>-><LANDROVER>
+ Add CLIO3-EPS-XC164CS-32F option in <7-OTHER>-><RENAULT>
+ Add CDC-XC164CS-16F option in <7-OTHER>-><SACHS>
+ Add AIRBAG-VW52 option in <7-OTHER>-><VOLKSWAGEN>

Free download VVDI Prog V4.4.8

Free download VVDI Prog 4.4.8 software

https://mega.nz/#!H85gWTKR!54g3BGkJd-E2Juhl6iXZGBqtodK_HGlwPb8t515G65Q

password:123456

VVDI Prog V4.4.8 Update feature:
* This version DON’t need update firmware
* Fix some bugs (write or erase operation prompt device error problem)

Free download VVDI-PROG programmer V4.4.5

https://mega.nz/#!ChoVjaSZ!_kOrS-BUt_ydU-CALN1vcuZbd4YNf6vX4Ii6QB0gwew

password:123456

VVDI-Prog v4.4.5 update feature (2016-05-25):
* This version DON’t need update firmware
* Fix some bugs
* Fix MC9S12XE seires write
P-FLASH bug
(write BMW FRM bug)
+ Add VVDI PROG USER MUNUAL in
Doc folder
+ Add 12V power output status in
software
+ Add MC9S08LG16_UNSECURED,
MC9S08LG32_UNSECURED,
MC9S08MP12_UNSECURED,
MC9S08MP16_UNSECURED,
MC9S08SC4_UNSECURED,
MC9S08SG4_UNSECURED,
MC9S08SG8_UNSECURED,
MC9S08SG16_UNSECURED,
MC9S08SG32_UNSECURED,
MC9S08SF4_UNSECURED,
MC9S08SV8_UNSECURED,
MC9S08SV16_UNSECURED options
in <2-MCU>-><MOTOROLA-MC9S08>
+ Add MC68HC12BC32_UNSECURED,
MC68HC12BE32_UNSECURED,
MC68HC912B32_UNSECURED,
MC68HC912BC32_UNSECURED,
MC68HC912BD32_UNSECURED,
MC912D60_UNSECURED,
MC912D60A_UNSECURED,
MC912DG128_UNSECURED,
MC912DG128A_UNSECURED,
MC68HC912BD32_SECURED,
MC912D60_SECURED,
MC912D60A_SECURED,
MC912DG128_SECURED,
MC912DG128A_SECURED options
in <2-MCU>->
<MOTOROLA-MC68HC(9)12>
+ Add MC9S12H128_UNSECURED,
MC9S12H256_UNSECURED,
MC9S12H128_SECURED,
MC9S12H256_SECURED options
Mask:(0K78X,1K78X)
MC9S12XF128_UNSECURED,
MC9S12XF256_UNSECURED,
MC9S12XF384_UNSECURED,
MC9S12XF512_UNSECURED,
MC9S12XF128_SECURED,
MC9S12XF256_SECURED,
MC9S12XF384_SECURED,
MC9S12XF512_SECURED options
Mask:(0M64J,1M64J,2M64J)
in <2-MCU>-><MOTOROLA-MC9S12>
+ Add R5F2154XX-RESET-SEC,
R5F21546E,
R5F21547E,
R5F21548E,
R5F2154AE,
R5F2154CE,
R5F21546F,
R5F21547F,
R5F21548F,
R5F2154AF,
R5F2154CF,
R5F21546G,
R5F21547G,
R5F21548G,
R5F2154AG,
R5F2154CG,
R5F21546H,
R5F21547H,
R5F21548H,
R5F2154AH,
R5F2154CH options
in <2-MCU>-><RENESAS-R8C>
+ Add D70F3416,
D70F3417,
D70F3421,
D70F3422,
D70F3423,
D70F3424,
D70F3425,
D70F3426,
D70F3427,
D70F3433,
D70F3610,
D70F3611,
D70F3612,
D70F3613,
D70F3614,
D70F3615,
D70F3616,
D70F3617,
D70F3618,
D70F3619,
D70F3620,
D70F3621,
D70F3622,
D70F3624,
D70F3628,
D70F3634 options
in <2-MCU>-><RENESAS-V850>
+ Add BCM2(D70F3379),
BCM2(D70F3381/3634) options
in <4-IMMOBILIZER>-><AUDI>
+ Add BCM2(D70F3379),
BCM2(D70F3381/3634) options
in <4-IMMOBILIZER>-><VOLKSWAGEN>
+ Add EXCELLE(2010),
EXCELLE(2013-15),
GL8-FIRSTLAND(2007),
LACROSSE(2008) options
in <5-DASHBORAD>-><BUICK>
+ Add YUEXIANG(2014) option
in <5-DASHBORAD>-><CHANGAN>
+ Add FOCUS(2005),
MONDEO-CHIA-X(2009),
S-MAX(2008) options
in <5-DASHBORAD>-><FORD>
+ Add LOBO(2008) option
in <5-DASHBORAD>-><HAFEI>
+ Add FAMILY(2011-13) option
in <5-DASHBORAD>-><HAIMA>
+ Add S-SEIRES option
in <5-DASHBORAD>-><JAGUAR>
+ Add JINBEI(2015) option
in <5-DASHBORAD>-><JINBEI>
+ Add LANDWIND-X8 option
in <5-DASHBORAD>-><JMC>
+ Add XC60(2016) option
in <5-DASHBORAD>-><VOLVO>
+ Add FSV(2010-) option
in <5-DASHBORAD>-><ZHONGHUA>
+ Add SR7 option
in <5-DASHBORAD>-><ZOTYE>

VVDI-Prog V4.4.4 update feature (2016-04-25)

* This version DON’t need update
firmware
* Fix some bugs
* Change some prompt information
* Fix MC9S12 seires some types
write EEPROM error
+ Add upgrade info prompt, when the
new version software upgrade auto
display the update information
+ Add Frequency Set botton in
MC9S12 seires UNSECURED version,
support manual set frequency or
search the right frequency from
MC9S12_BADURATE.cfg in Data folder
(support add frequency parameter)
+ Add Frequency Set botton in
RENESAS-V850 seires, support manual
set frequency or search the right
frequency from V850_BADURATE.cfg
in Data folder
(support add frequency parameter)
+ Add Frequency Set botton in
RENESAS-R5F61XXX seires, support
manual set frequency or search
the right frequency from
R5F61XXX_BADURATE.cfg in Data folder
(support add frequency parameter)
+ Add MC9S08AC8_UNSECURED,
MC9S08AC16_UNSECURED,
MC9S08AC32_UNSECURED,
MC9S08AC48_UNSECURED,
MC9S08AC60_UNSECURED,
MC9S08AC96_UNSECURED,
MC9S08AC128_UNSECURED,
MC9S08AW8_UNSECURED,
MC9S08AW16_UNSECURED,
MC9S08AW32_UNSECURED,
MC9S08AW48_UNSECURED,
MC9S08AW60_UNSECURED,
MC9S08DV16_UNSECURED,
MC9S08DV32_UNSECURED,
MC9S08DV48_UNSECURED,
MC9S08DV60_UNSECURED,
MC9S08DV96_UNSECURED,
MC9S08DV128_UNSECURED,
MC9S08DZ16_UNSECURED,
MC9S08DZ32_UNSECURED,
MC9S08DZ48_UNSECURED,
MC9S08DZ60_UNSECURED,
MC9S08DZ96_UNSECURED,
MC9S08DZ128_UNSECURED,
MC9S08EL16_UNSECURED,
MC9S08EL32_UNSECURED,
MC9S08FL8_UNSECURED,
MC9S08FL16_UNSECURED,
MC9S08GB32_UNSECURED,
MC9S08GB60_UNSECURED,
MC9S08GT16_UNSECURED,
MC9S08GT32_UNSECURED,
MC9S08GT60_UNSECURED,
MC9S08JS8_UNSECURED,
MC9S08JS16_UNSECURED,
MC9S08QA2_UNSECURED,
MC9S08QA4_UNSECURED,
MC9S08QD2_UNSECURED,
MC9S08QD4_UNSECURED,
MC9S08QG4_UNSECURED,
MC9S08QG8_UNSECURED,
MC9S08SE4_UNSECURED,
MC9S08SE8_UNSECURED,
MC9S08SH4_UNSECURED,
MC9S08SH8_UNSECURED,
MC9S08SL8_UNSECURED,
MC9S08SL16_UNSECURED options
in <2-MCU>->
+ Add R5F61723 option
in <2-MCU>->
+ Add QUADROCYCLE(2011) option
in <3-ECU>->
+ Add H2-BCM option
in <4-IMMOBILIZER>->
+ Add BENBEN,
S35,
JINNIUXING,
YUEXIANG options
in <5-DASHBORAD>->
+ Add CAPTIVA(2008) option
in <5-DASHBORAD>->
+ Add VENUCIA-R50(2014),
XIAOKANG(2014) options
in <5-DASHBORAD>->
+ Add BESTURN-B50,
BESTURN-B90(2014),
BESTURN-X80(2013),
VITA(2008) options
in <5-DASHBORAD>->
+ Add FOCUS(09-10) option
in <5-DASHBORAD>->
+ Add C30(2010) option
in <5-DASHBORAD>->
+ Add S5 option
in <5-DASHBORAD>->
+ Add LUXGEN option
in <5-DASHBORAD>->
+ Add QASHQAI(2011) option
in <5-DASHBORAD>->
+ Add BAOJUN730(2015),
ROEWE550,
SGMW-WULINGZHIGUANG options
in <5-DASHBORAD>->
+ Add S40(2006-08),
S40(2010),
XC60(2012) options
in <5-DASHBORAD>->
+ Add V5 option
in <5-DASHBORAD>->
+ Add Z300(2013) option
in <5-DASHBORAD>->
+ Add ISM-W221,
LU-W221,
SAM-W221 options
in <7-OTHER>->
+ Add RFA option
in <7-OTHER>->
+ Add PASSAT-B6-PBCM option
in <7-OTHER>->

VVDIProg v4.4.3 update feature (2016-03-31)
* This version DON’t need update
firmware
+ Add R5F61725 option
in <2-MCU>-><RENESAS>
+ Add MC9S12HZ128_UNSECURED,
MC9S12HZ256_UNSECURED,
MC9S12KG128_UNSECURED,
MC9S12KG256_UNSECURED,
MC9S12KT128_UNSECURED,
MC9S12KT256_UNSECURED,
MC9S12XEA128_UNSECURED,
MC9S12XEG128_UNSECURED,
MC9S12XEA256_UNSECURED,
MC9S12XEG256_UNSECURED,
MC9S12XET256_UNSECURED,
MC9S12XEG384_UNSECURED,
MC9S12XEQ384_UNSECURED,
MC9S12XES384_UNSECURED,
MC9S12XEQ512_UNSECURED,
MC9S12XET512_UNSECURED,
MC9S12XEP768_UNSECURED,
MC9S12XEP100_UNSECURED,
MC9S12XHZ256_UNSECURED,
MC9S12XHZ384_UNSECURED,
MC9S12XHZ512_UNSECURED,
MC9S12HZ128_SECURED,
MC9S12HZ256_SECURED,
MC9S12KG128_SECURED,
MC9S12KG256_SECURED,
MC9S12KT128_SECURED,
MC9S12KT256_SECURED,
MC9S12XEA128_SECURED,
MC9S12XEG128_SECURED,
MC9S12XEA256_SECURED,
MC9S12XEG256_SECURED,
MC9S12XET256_SECURED,
MC9S12XEG384_SECURED,
MC9S12XEQ384_SECURED,
MC9S12XES384_SECURED,
MC9S12XEQ512_SECURED,
MC9S12XET512_SECURED,
MC9S12XEP768_SECURED,
MC9S12XEP100_SECURED,
MC9S12XHZ256_SECURED,
MC9S12XHZ384_SECURED,
MC9S12XHZ512_SECURED diagram
in <2-MCU>-><MOTOROLA>
+ Add SGMW-HONGGUANG option
in <5-DASHBORAD>-><CHERY>
+ Add 315M-IN-CIRCUIT,
315M-CHIP,
434M-IN-CIRCUIT,
434M-CHIP,
868M-IN-CIRCUIT,
868M-CHIP options in
<6-REMOTE>-><BMW-E-SERIES-RENEW>

Free download VVDI-Prog V4.4.3 software
https://mega.nz/#!C59zDJKQ!F9-c40k4C1ZUTzghQmDNW7B-Et8HPr5QO3AV17jW2_8

Password: 123456

Free download VVDIProg V4.4.2

VVDI-Prog v4.4.2 updated features:
* This version DON’t need update
firmware
+ Add MC9S12A64_UNSECURED,
MC9S12A128_UNSECURED,
MC9S12A256_UNSECURED,
MC9S12D64_UNSECURED,
MC9S12DB128_UNSECURED,
MC9S12DG128_UNSECURED,
MC9S12DG256_UNSECURED,
MC9S12DJ64_UNSECURED,
MC9S12DJ128_UNSECURED,
MC9S12DJ256_UNSECURED,
MC9S12DP256_UNSECURED,
MC9S12DT128_UNSECURED,
MC9S12DT256_UNSECURED,
MC9S12GN16_UNSECURED,
MC9S12GNA16_UNSECURED,
MC9S12GN32_UNSECURED,
MC9S12GNA32_UNSECURED,
MC9S12G48_UNSECURED,
MC9S12GA48_UNSECURED,
MC9S12GN48_UNSECURED,
MC9S12G64_UNSECURED,
MC9S12GA64_UNSECURED,
MC9S12G96_UNSECURED,
MC9S12GA96_UNSECURED,
MC9S12G128_UNSECURED,
MC9S12GA128_UNSECURED,
MC9S12G192_UNSECURED,
MC9S12GA192_UNSECURED,
MC9S12G240_UNSECURED,
MC9S12GA240_UNSECURED,
MC9S12XA128_UNSECURED,
MC9S12XA256_UNSECURED,
MC9S12XDA512_UNSECURED,
MC9S12XB128_UNSECURED,
MC9S12XB256_UNSECURED,
MC9S12XD64_UNSECURED,
MC9S12XD128_UNSECURED,
MC9S12XD256_UNSECURED,
MC9S12XDG128_UNSECURED,
MC9S12XDP512_UNSECURED,
MC9S12XDQ256_UNSECURED,
MC9S12XDT256_UNSECURED,
MC9S12XDT384_UNSECURED,
MC9S12XDT512_UNSECURED,
MC9S12A64_SECURED,
MC9S12A128_SECURED,
MC9S12A256_SECURED,
MC9S12D64_SECURED,
MC9S12DJ64_SECURED,
MC9S12DB128_SECURED,
MC9S12DJ128_SECURED,
MC9S12DG128_SECURED,
MC9S12DT128_SECURED,
MC9S12DG256_SECURED,
MC9S12DJ256_SECURED,
MC9S12DP256_SECURED,
MC9S12DT256_SECURED,
MC9S12XA128_SECURED,
MC9S12XA256_SECURED,
MC9S12XDA512_SECURED,
MC9S12XB128_SECURED,
MC9S12XB256_SECURED,
MC9S12XD64_SECURED,
MC9S12XD128_SECURED,
MC9S12XDG128_SECURED,
MC9S12XD256_SECURED,
MC9S12XDQ256_SECURED,
MC9S12XDT256_SECURED,
MC9S12XDT384_SECURED,
MC9S12XDP512_SECURED,
MC9S12XDT512_SECURED diagram
in <2-MCU>-><MOTOROLA>
+ Add [V850E/Ix3] seires:
D70F3451,
D70F3452,
D70F3453,
D70F3454 diagram
[V850ES/Jx3] seires:
D70F3739,
D70F3740,
D70F3741,
D70F3742,
D70F3743,
D70F3744,
D70F3745,
D70F3746 diagram
[V850ES/Jx3-E] seires:
D70F3778,
D70F3779,
D70F3780,
D70F3781,
D70F3782,
D70F3783,
D70F3784,
D70F3785,
D70F3786,
D70F3826,
D70F3827,
D70F3828,
D70F3829,
D70F3834,
D70F3835,
D70F3836,
D70F3837 diagram
[SPECIAL TYPE] seires:
D70F3469 diagram
in <2-MCU>-><RENESAS>
+ Add A4L-BCM(1L15Y) option
in <4-IMMOBILIZER>-><AUDI>
+ Add CAS4-5M48H-UNLOCK,
CAS4-1N35H-UNLOCK options
in <4-IMMOBILIZER>-><BMW>
+ Add VECTRA(2004-2008) option
in <4-IMMOBILIZER>-><OPEL>
+ Add BCM-2M25J-UNLOCK,
BCM-5M48H-UNLOCK,
BCM-1N35H-UNLOCK options
in <4-IMMOBILIZER>-><PORSCHE>
+ Add NEW-QQ option
in <5-DASHBORAD>-><CHERY>
+ Add KUGA-3L16Y option
in <5-DASHBORAD>-><FORD>
* Fix some bug
————————————-
VVDI Prog programmer v4.4.1 (2016-03-17)
* This version need update
firmware
The latest version is 2.0.0
The new version will support
more versions of driver
* Get this version software in
4.4.0 version Upgrade option
+ Add MC9S12C32_UNSECURED,
MC9S12C64_UNSECURED,
MC9S12C96_UNSECURED,
MC9S12C128_UNSECURED,
MC9S12GC16_UNSECURED,
MC9S12GC32_UNSECURED,
MC9S12GC64_UNSECURED,
MC9S12GC96_UNSECURED,
MC9S12GC128_UNSECURED,
MC9S12GC16_SECURED,
MC9S12GC32_SECURED,
MC9S12GC64_SECURED,
MC9S12GC96_SECURED,
MC9S12GC128_SECURED options
in <2-MCU>-><MOTOROLA>
Mask:(0M66G,1M34C,1L45J,2L45J)
+ Add [V850ES/Sx3]series:
D70F3231,
D70F3232,
D70F3233,
D70F3234,
D70F3235,
D70F3236,
D70F3237,
D70F3238,
D70F3239 options
[V850E/RS1]series:
D70F3402,
D70F3403,
D70F3403A options
[V850E/Ix3]series:
D70F3451,
D70F3452,
D70F3453,
D70F3454 options
[V850E/RG3]series:
D70F3464,
D70F3465,
D70F3466,
D70F3470,
D70F3471,
D70F3472 options
[V850ES/Jx2]series:
D70F3715,
D70F3716,
D70F3717,
D70F3718,
D70F3719,
D70F3720,
D70F3721,
D70F3722,
D70F3723,
D70F3724 options
[V850ES/Jx3]series:
D70F3739,
D70F3740,
D70F3741,
D70F3742,
D70F3743,
D70F3744,
D70F3745,
D70F3746 options
[SPECIAL TYPE]series:
D70F3469 options
[V850ES/Jx3-E]series:
D70F3778,
D70F3779,
D70F3780,
D70F3781,
D70F3782,
D70F3783,
D70F3784,
D70F3785,
D70F3786,
D70F3826,
D70F3827,
D70F3828,
D70F3829,
D70F3834,
D70F3835,
D70F3836,
D70F3837 options
in <2-MCU>-><RENESAS>
+ Add the OPBT0 area in
<2-MCU>-><RENESAS> :
D70F3522,
D70F3523,
D70F3524,
D70F3525,
D70F3526,
D70F3529,
D70F3532,
D70F3535,
D70F3536,
D70F3537,
D70F4177,
D70F4178,
D70F4179,
D70F4180 options
The OPBT0 area is the chip config
data area
+ Add EIS-W220(HC08) option
in <4-IMMOBILIZER>-><BENZ>
+ Add IMMOBILIZER-0J66D,
IMMOBILIZER-0L72A,
IMMOBILIZER-1H56A,
IMMOBILIZER-1K59H options
in <4-IMMOBILIZER>-><FIAT>
+ Add SMARTKEY-0L01Y option
in <4-IMMOBILIZER>-><JAGUAR>
+ Add BCM-1N35H-BACKUP,
BCM-1N35H-R/W/UNLOCK options
in <4-IMMOBILIZER>-><PORSCHE>
+ Add H5-1M80F option in
<5-DASHBORAD>-><GREATWALL>
+ Add XC60(2014) option in
<5-DASHBORAD>-><VOLVO>
+ Add FRM-XEQ384 option
in <7-OTHER>-><BMW>
+ Add auto backup the security area
1K Bytes data function in
MC9S12XE series chip options when
select unlock the chip, the backup
data will be saved in “backup”
folder and named with time info
+ Add auto detect firmware version
function. if the firmware
version too low, the software
will prompt to upgrade the
firmware
* Fix some bug

VVDIProg4.4.0 (2016-03-07)

* This version DOESN’t need update firmware

* Add the Download Link in Upgrade option, click it and get the last version software!!!

* Change the diagram interface

+ Add MC9S12C32_SECURED,MC9S12C64_SECURED,MC9S12C96_SECURED,MC9S12C128_SECURED in <2-MCU>->

Mask:(0M66G,1M34C,1L45J,2L45J)

+ Add EIZ-W164(ST12),EIZ-W215(ST12),EIZ-W221(ST12),EIZ-VANEO(ST12) options in <4-IMMOBILIZER>->

+ Add CAPTIVA(2011) option in<5-DASHBORAD>->

+ Add BAOJUN330 option in<5-DASHBORAD>->

+ Add C70(2011) option in <5-DASHBORAD>->

VVDIProg V4.3.1 (2016-01-27)

* This version DOESN’t need update firmware

+ Add MC9S12GN16_UNSECURED,

MC9S12GNA16_UNSECURED,

MC9S12GN32_UNSECURED,

MC9S12GNA32_UNSECURED,

MC9S12G48_UNSECURED,

MC9S12GA48_UNSECURED,

MC9S12GN48_UNSECURED,

MC9S12G64_UNSECURED,

MC9S12GA64_UNSECURED,

MC9S12G96_UNSECURED,

MC9S12GA96_UNSECURED,

MC9S12G128_UNSECURED,

MC9S12GA128_UNSECURED,

MC9S12G192_UNSECURED,

MC9S12GA192_UNSECURED,

MC9S12G240_UNSECURED,

MC9S12GA240_UNSECURED options

Mask:(0N95B,0N51A,0N75C,1N75C,

0N48A,1N48A)

MC9S12HA32_UNSECURED,

MC9S12HA48_UNSECURED,

MC9S12HA64_UNSECURED,

MC9S12HY32_UNSECURED,

MC9S12HY48_UNSECURED,

MC9S12HY64_UNSECURED options

Mask:(0M34S)

MC9S12P32_UNSECURED,

MC9S12P64_UNSECURED,

MC9S12P96_UNSECURED,

MC9S12P128_UNSECURED options

Mask:(0M01N)

MC9S12XEA128_UNSECURED,

MC9S12XEG128_UNSECURED,

MC9S12XEA128_SECURED,

MC9S12XEG128_SECURED options

Mask:(1M53J,2M53J,0N36H,1N36H)

MC9S12XHY128_UNSECURED,

MC9S12XHY256_UNSECURED options

Mask:(0M23Y)

MC9S12XS64_UNSECURED,

MC9S12XS128_UNSECURED,

MC9S12XS256_UNSECURED options

Mask:(0M04M,1M04M,0M05M) in <2-MCU>->

+ Add MC9S12XE_UNLOCK option in <2-MCU>->

(Backup all data before use it)

+ Add ME20U2-XET256-BACKUP,

ME20U2-XET512-BACKUP,

MT22-XEP768-BACKUP,

MT60-XEP768-BACKUP options in <3-ECU>->

+ Add the 12V power adaptor status in information dialog
VVDI PROG V4.3.0 (2016-01-16)

* This version DOESN’t need update firmware

+ Add MC9S12XHZ256_UNSECURED,

MC9S12XHZ384_UNSECURED,

MC9S12XHZ512_UNSECURED,

MC9S12XHZ256_SECURED,

MC9S12XHZ384_SECURED,

MC9S12XHZ512_SECURED options

in <4-IMMOBILIZER>->Mask:(0M80F,1M80F)

+ Add [V850ES/Sx3]series:

D70F3333,

D70F3334,

D70F3335,

D70F3336,

D70F3340,

D70F3341,

D70F3342,

D70F3343,

D70F3350,

D70F3351,

D70F3352,

D70F3353,

D70F3344,

D70F3345,

D70F3346,

D70F3347,

D70F3348,

D70F3354,

D70F3355,

D70F3356,

D70F3357,

D70F3358,

D70F3364,

D70F3365,

D70F3366,

D70F3367,

D70F3368 options

[V850ES/Fx3]series:

D70F3370A,

D70F3371,

D70F3372,

D70F3373,

D70F3374,

D70F3375,

D70F3376A,

D70F3377A,

D70F3378,

D70F3379,

D70F3380,

D70F3381,

D70F3382,

D70F3383,

D70F3384,

D70F3385 options

[V850ES/Hx2]series:

D70F3700,

D70F3701,

D70F3702,

D70F3703,

D70F3704,

D70F3706,

D70F3707,

D70F3709,

D70F3710,

D70F3711,

D70F3712 options

[V850E2/Fx4-G]series:

D70F4177,

D70F4178,

D70F4179,

D70F4180 options

in <2-MCU>->

+ Add EIZ-W220(ST12)

in <4-IMMOBILIZER>->

+ Add ORIGINAL-315M-IN-CIRCUIT,

ORIGINAL-315M-CHIP,

ORIGINAL-868M-IN-CIRCUIT,

ORIGINAL-868M-CHIP options in

<6-REMOTE>->

* Modify the EXCELLE(2013–)BCM,

EXCELLE-GT(2013–)BCM,

EXCELLE(2014) options in

<4-IMMOBILIZER>->:

Remove the D-FLASH option

* Modify the CAS4-5M48H-R/W/UNLOCK,

CAS4-1N35H-R/W/UNLOCK options

in <4-IMMOBILIZER>->:

Autoset the D-FLASH partition

size as 32K while writing the

D-FLASH data
VVDI PROG V4.1.4 (2015-12-11)
* This version DOESN’t need to update firmware

* Fix when the partition size information error in MC9S12XE series chips manual set the partition size function error problem

VVDI PROG V4.1.3 (2015-12-11)

* This version DOESN’t need to update firmware

+ Add PA28F200B5T(PSOP44),

PA28F200B5B(PSOP44),

PA28F200BVT(PSOP44),

PA28F200BVB(PSOP44),

PA28F200BXT(PSOP44),

PA28F200BXB(PSOP44),

PA28F400B5T(PSOP44),

PA28F400B5B(PSOP44),

PA28F400BVT(PSOP44),

PA28F400BVB(PSOP44),

PA28F400BXT(PSOP44),

PA28F400BXB(PSOP44),

PA28F800B5T(PSOP44),

PA28F800B5B(PSOP44),

PA28F800BVT(PSOP44),

PA28F800BVB(PSOP44),

PA28F800BXT(PSOP44),

PA28F800BXB(PSOP44),

TB28F200B5T(PSOP44),

TB28F200B5B(PSOP44),

TB28F200BVT(PSOP44),

TB28F200BVB(PSOP44),

TB28F200BXT(PSOP44),

TB28F200BXB(PSOP44),

TB28F400B5T(PSOP44),

TB28F400B5B(PSOP44),

TB28F400BVT(PSOP44),

TB28F400BVB(PSOP44),

TB28F400BXT(PSOP44),

TB28F400BXB(PSOP44),

TB28F800B5T(PSOP44),

TB28F800B5B(PSOP44),

TB28F800BVT(PSOP44),

TB28F800BVB(PSOP44),

TB28F800BXT(PSOP44),

TB28F800BXB(PSOP44)options in <1-EEPROM&FLASH>->(Need the TB28FXXX adapter)

+ Add XP8000E option in <3-ECU>->

+ Add BCM-XEQ384 option in <4-IMMOBILIZER>->

+ Add Laguna BCM(2010–)option in <4-IMMOBILIZER>->

+ Add EXCELLE(2011–)(3L16Y)option in <5-DASHBORAD>->

* Fix the MC9S12XE series”read partition” software bug

* Change the default connection diagram size to 50%

VVDI PROG V4.1.2 (2015-11-27)
* This version DoesN’t need to update firmware

+ Add MC9S12A64_UNSECURED

MC9S12D64_UNSECURED

MC9S12DJ64_UNSECURED

MC9S12A128_UNSECURED

MC9S12DB128_UNSECURED

MC9S12DG128_UNSECURED

MC9S12DJ128_UNSECURED

MC9S12DT128_UNSECURED

MC9S12HZ128_UNSECURED

MC9S12KG128_UNSECURED

MC9S12KT128_UNSECURED

MC9S12A256_UNSECURED

MC9S12DG256_UNSECURED

MC9S12DJ256_UNSECURED

MC9S12DP256_UNSECURED

MC9S12DT256_UNSECURED

MC9S12HZ256_UNSECURED

MC9S12KG256_UNSECURED

MC9S12KT256_UNSECURED

MC9S12XA128_UNSECURED

MC9S12XB128_UNSECURED

MC9S12XD128_UNSECURED

MC9S12XDG128_UNSECURED

MC9S12XA256_UNSECURED

MC9S12XB256_UNSECURED

MC9S12XD256_UNSECURED

MC9S12XDQ256_UNSECURED

MC9S12XDT256_UNSECURED

MC9S12XDT384_UNSECURED

MC9S12XDA512_UNSECURED

MC9S12XDP512_UNSECURED

MC9S12XDT512_UNSECURED options in <2-MCU>->, support auto detect the clk frequency,read/write the unsecured chip with standard BDM interface

+ Add MC9S12XA128,MC9S12XB128,MC9S12XD128,MC9S12XDG128 options in <2-MCU>->Mask:(0M42E,1M42E,2M42E)

+ Add MC9S12XA256,MC9S12XB256,MC9S12XD256,MC9S12XDQ256,MC9S12XDT256 options in <2-MCU>->Mask:(0M84E,1M84E)

+ Add BCM-XDT384,BCM-XEG384 options in <4-IMMOBILIZER>->

+ Add EXCELLE(2013–)BCM,EXCELLE-GT(2013–)BCM options in <4-IMMOBILIZER>->

+ Add MG7 option in <4-IMMOBILIZER>->

+ Add EIZ-SPRINTER(2015–) option in <4-IMMOBILIZER>->

+ Add ZAFIRA-DG128,ASTRA-DG128 options in <4-IMMOBILIZER>->
VVDI PROG V4.1.1 (2015-11-19)
* This version Doesn’t need to update firmware

+ Add Delphi ECU MT20U2-2L33V option in <3-ECU>->

+ Add NEW SAIL BCM option in <4-IMMOBILIZER>->

+ Add ROEWE750 immobox option in <4-IMMOBILIZER>->

+ Add EXCELLE 2014 option in<5-DASHBORAD>->

* Fix display problem while check failure

VVDI PROG 4.1.0 (2015-11-13)

* The need to upgrade the firmware upgrade
+ <2- SCM> – option to increase
MC9S12XEA256 unencrypted,
MC9S12XEG256 unencrypted,
MC9S12XET256 unencrypted,
MC9S12XEG384 unencrypted,
MC9S12XEQ384 unencrypted,
MC9S12XES384 unencrypted,
MC9S12XEQ512 unencrypted,
MC9S12XET512 unencrypted,
MC9S12XEP768 unencrypted,
MC9S12XEP100 unencrypted Options
It supports automatic clock frequency judgment,
Supports four- read unencrypted chip
+ <3-ECU> – increase ME20U2-XET256, ME20U2-XET512 Options
+ <3-ECU> – increase MT22-XEP768, MT60-XEP768 Options
+ <4- theft> – option to increase CAS3-2K79X, CAS3-0L01Y,CAS3 + (0L15Y), CAS3 + (0M23S) Options
* Fixed Shanghai SIIC Transportation Security boxes given problem

V3.8.0 VVDI PROG Programmer Update Information:

V3.8.0 (2015-09-22)
* This version DOESN’t need to update firmware

+ Add 2L33V, 3L15Y R/W function (The only equipment can R/W except original equipment)

+ Add MC9S12HZ128, MC9S12HZ256, MC9S12KG128, MC9S12KG256, MC9S12KT128, MC9S12KT256 options in <2-MCU>–>Mask:(2L16Y,3L16Y,0L74N,1L74N,2L14N,3L74N,4L74N,5L74N,0L33V,1L33V,2L33V,3L33V,0M17D)

+ Add SIEMENS VDO IMMOBILIZER (0L72A_E/1K59H_E)in <4-IMMOBILIZER>options

+ Add “CAS4-1N35H-BACKUP”,”CAS4-1N35H-R/W” options in <4-IMMOBILIZER>–>

+ Add CHERY E5 option in<5-DASHBORAD>

+ Add tips about erase confirmation

* Change Great Wall immobox connection diagram

* Fix the English Version display problem

V3.6.0 (2015-09-15)
* This version DOESN’t need update firmware

+ Add SIEMENS/STEC IMMOBILIZER in<4-IMMOBILIZER>(0L07H/0L59X/0L72A/3K59G)

+ Add BMW EWS4.X in <4-IMMOBILIZER>

+ Add FORD BCM 7S7T in <4-IMMOBILIZER>

+ Add MC9S12XDT384 option in <2-MCU>->, support 0L86D/1L86D/2L86D/3L86D/4L86D/0M89C) options

* Fix MC9S12xx64 Crack/Read/Write function

V3.4.0 (2015-09-10)
* This version DOESN’T need update firmware

+ Add Porsche BCM (1L15Y/2M25J/5M48H) options

+ Add MC9S12XEQ512,MC9S12XET512 options in <2-MCU>–>Motorola

+ Add BENZ EIS-W203 in <4-IMMOBILIZER>

* Fix some display BUGs in English Version

* Change the name of upgrade button as “Start Firmware Upgrade”

* Change the Voltage name as “VCC”,”VPP”

Related Post:

How to update Xhorse VVDI Prog software ?

VVDI-Prog programmer read BMW ECU ISN

VVDI Prog read and write PCF79XX chip
VVDI-Prog programmer adds BMW CAS4 key
