This is a instruction on how to program VAG group VW Audi Skoda Seat keys using Xhorse VAG KM+IMMO Tool OBD2 cable when all keys are lost.
Here is the procedure of new keys programming by VAG KM+IMMO OBDII Tool:
1) Connect “VAG KM+IMMO Tool” to both pc and car.
2) Click “Service Mode” button to open “Service Mode” dialog.
3) Remove the 24C32 chip from instrument, read 24C32 EEPROM data with programmer, and save EEPROM.
4) Switch to “Service Mode” dialog, load EEPROM.
5) Save special EEPROM, write data to 24C32 EEPROM back to the chip,
and install chip back in instrument.
6) Save KEY file.
7) Login with the key file.
Click “Write” button to write back the original EEPROM (via OBDII).
9) Close “Service Mode” dialog, start adding dealer key (Click “Dealer Key” button, open “Dealer key” dialog.)
Note: Before the process is complete, keep the PC and device connected with vehicle, do NOT disconnect. If you interrupt, you
need to re-start from the first step.
VAG KM+IMMO Tool VAG key programmer & mileage programmer car list:
CDC32xx Module Options:
Golf, Golf+ from year 2007 (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
odometer correction, PIN code read, EEPROM read/write;
Passat B6 from year 2007 (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
EEPROM read/write;
Bora, Jetta from year 2007 (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
odometer correction, PIN code read, EEPROM read/write;
Touran from year 2007 (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
odometer correction, PIN code read, EEPROM read/write;
Caddy from year 2007 (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
odometer correction, PIN code read, EEPROM read/write;
Tiguan, Eos from year 2008+: odometer correction, PIN code read, EEPROM read/write;
Octavia (with MICRONAS CDC3272 or CDC3217/97 and 24C32 EEPROM):
odometer correction, PIN code read, EEPROM read/write
NEC 24C32 Module Options:
VW Golf 6 – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Passat , Passat CC – 2009+ with NEC and 24C32 EEPROM – odometer programming by OBDII;
VW Tiguan – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW T5 – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Polo – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Octavia 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda SuperB – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Roomster, Yeti – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Seat Ibiza – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Multivan – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW EOS – 2009+ with NEC and 24C32 EEPROM – odometer programming by OBDII;
VW Caddy – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Scirocco – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Bora – 2010+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
VW Jetta – 2010+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Fabia 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Altea – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Yeti – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Altea – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
Skoda Exeo – 2009+ with NEC and 24C32 EEPROM – odometer programming and immobiliser data read by OBDII;
GOLF6 MM7 Module Options:
VW Golf 6 – 2010 with MM7 (9S12) EEPROM – odometer programming and immobiliser data read by OBDII;
VW Tiguan – 2010+ with MM7 (9S12) EEPROM – odometer programming and immobiliser data read by OBDII;
